ML-401

Model: ML-401

Features
Specification

Features

● World First Dense-ball Bearing

Provide rapid, stable and durable performance.

● All-Weather Dependability

The advanced protection against rainfall and dropping in different environment.

● Laser Pointer to Increase Work Efficiency

The built-in coaxial laser pointers that maximize the efficiency by its 250m working range.

● Code Disk in 360 Degrees

The operation error can be largely reduced by dual-side measurement.

● Power-Saving Technology Saves Battery Costs

Two AA alkaline batteries provide long operating time.

1new-1912

Specification

Accuracy	Laser Pointer	1/45000
Accuracy	Laser Plumb	1/2000
Telescope	Image	Reverse
	Magnification	28x
	Sight of View	1°30′
	Effective Aperture	40mm
	Min. Focus	0.8m
Laser Pointer	Diameter at 50m	3mm
	Visible Distance	70m
	Max. Distance at Day	≥200m
	Max. Distance at Night	≥250m
	Wavelength	635nm
	Output Power	1mw
	Error of co-axis	5″
Laser Plumb	Diameter at 1.5m	1mm
	Max. Distance	2m
	Wavelength	650nm
	Output Power	1mw
	Laser Source	Laser Diode
Others	Plate Vial	30″/2mm
	Power Supply	2pcs AA Battery
	Working Hours	8 Hours
	Output Power	1mw
	Error of co-axis	5″

Note: all information above is subject to change without any prior notice.
