Specification

LiDAR System	Laser Channels	--
	Laser Range	max. 330 m
	Field of View	0°~ 360°
	Angular Resolution	0.001°
	Max. Means Rate	up to 200,000 meas./sec
	Accuracy	H/V: 5 cm @50 m; H/V: 10 cm@100 m (UAV) H/V: 3 cm (Automotive)
	Camera Effective Pixels	24.3 MP RGB
	Recommended scanning height AGL	10-160 m
	Net Weight	2.5 kg (w/o camera)
	Dimensions	307 x 94 x 116 mm
	Input Voltage	11-32V DC
	Power Consumption	27 W
	Data Storage	--
Part I: Laser Scanner	Type	RIEGL miniVUX-2UAV
	Wavelength	1550 nm
	Eye Safety Class	laser class 1
	Laser Product Classification	--
	Laser Pulse Repetition Rate	100 kHz / 200 kHz selectable
	Range Accuracy	--
	Accuracy/ Precision	15 mm / 10 mm
	Rotation Rate	--
	Scan Speed	10-100 scans/sec
	Multi-echo effect	up to 5 echoes per shot
	Data Storage	SDHC/SDXC 32 GB ( 128 GB max.)
	Environment Protection	IP64
	Temperature	operating: -10° to 40°C; storage: -20° to 50°C
Part II: POS System	Type	STIM300
	Gyroscopes Bias in-run Stability	0.5°per hour
	Gyroscopes Measurement Range	400 deg/sec
	Accelerometers Measurement Range	±10 g
	Post Processing Roll/Pitch Accuracy	0.006°
	Post Processing Heading Accuracy	0.019°
	Post Processing Position H/V Accuracy	0.01/0.02 m
	Post Processing Velocity H/V Accuracy	0.02/0.01 (m/s)
	Data Sampling Rate	POS: 125 Hz; Location: 5 Hz
	Internal Memory	16 GB

Note: all information above is subject to change without any prior notice.
