AQUA M10

    Model: M10

    Download:

    AQUA M10 Brochure

    Features

    Fully New Design, Improving Your Productivity


    The SOUTH M10 is a compact unmanned surveying vessel equipped with a single-beam echo sounder. It features a centimeter-level high-precision dual GNSS positioning and heading system, an inertial measurement system with attitude accuracy up to 0.25°, and intelligent navigation and measurement software based on the Android platform. It can autonomously navigate accurately along a preset route, collecting precise data even in complex water flow environments.


    Compared to other unmanned surveying vessels in the industry, the M10 is more portable (950mm in length), has better obstacle avoidance performance (40m), a higher maximum speed (7m/s), longer endurance (6 hours on one battery with a cruise speed of 2m/s), a wider operating range (2km on 2.4GHz), and better  environmental suitability (only 9cm draft).


    This newly designed unmanned surveying system is the ideal choice for bathymetric surveys in lakes, inland rivers, and coastal areas..


    微信图片_2026-02-02_153423_923

    Specification

    Performance Motor Engine High-efficiency ducted long-life brushless motor (three-level waterproof protection)
    Steering Mode Steering engine free, differential steering, reversible
    Cruise Speed 7m/s (Maximum Adaptable Flow Velocity: 3m/s)
    Battery Portable, intelligent management, hot-swappable ternary lithium battery, 28.8V/45Ah
    Controller System Android System
    Display 9.2-inch HD Display
    Communication Range 2.5km for smart remote control,unlimited range for 4G
    Function Supports various storage capacities, capable of vessel control, data collection, video viewing, and working mode switching
    GNSS Performance GNSS Antenna Dual antenna, supporting CORS and radio modes
    Radio Protocol SOUTH, TRIMTALK450S, TRIMMARKI, TRANSEOT, HI-TARGET, CHC, SATEL
    Velocity Measurement Accuracy 0.02m/s
    RTK Accuracy H:±(8+106 xD)mm V:±(15+106xD)mm D-Baseline length (Unit: mm)
    Orientation Accuracy Heading accuracy: 0.15°@1m baseline; Attitude accuracy: 0.25°@1m baseline
    INS Performance Supports integrated navigation and 1PPS; Attitude accuracy: 0.25°;
    6°/h (accuracy decays by 1m in 20s); Maximum IMU update rate: 200Hz
    Built-in Single Beam Echo Sounder Operating frequency 200 kHZ
    Beam angle 5°
    Depth range 0.15~100m
    Accuracy ±0.01 m + 0.1% x D (D is the Depth of Water)
    Software GeoSailor(Control & Acquisition) Survey planning, navigation, vessel control, Real-time trajectory/data/videos Multi-storage, auto-RTH/hovering; adjusts sound velocity via temperature sensor
    HySurvey(Data Post-Processing) Processes data: re-sampling, depth calibration, tide correction, coordinate conversion
    Enables custom result output, PPK post-processing, and undo/rollback for flexible operation
    Protection Anti-wave & Wind 3rd Wind Level & 2nd Wave Level
    Waterproof IP67
    Safety Protection Design 360°infrared night vision camera, Millimeter-wave radar, two indicate lights, Dual Ducted Propeller
    Double-hull anti-sinking design, anti-collision strips, temperature and humidity detection
    Physical Dimensions(LxWxH) 950mm x 500mm x 350mm
    Material Nano-carbon fiber polymer composite, new composite material
    Hull Design Trimaran
    Weight 6KG(Without Battery), 27.2kg(With Battery)
    Draft Depth 9cm
    Payload Mini Single-frequency Echo Sounder
    Electrlectrical Endurance 7 hrs @2m/s (single), long-life option available
    Motor Power Typical 850W each

    Note: all information above is subject to change without any prior notice.
